MTG-GM200 M.2 E Key to M Key Adapter for M.2 WiFi Module
Utilize M.2 E Key or A-E Key Module (like WiFi, Bluetooth or Dual Band Wireless Module) in Embedded Computer M Key Socket!
- PCIe x1 signal interface from main board M.2 M-Key slot
- USB2.0 signal interface from main board USB port to M.2 E Key socket
- 100% OS-transparent hardware bridge converter to support Windows, MAC and Linux
- Includes Cable for USB 2.0 signal interface from main board
- Require an empty M.2 M-Key slot and USB2.0 port in computer
*** Most M.2 WiFi module use PCIe interface, Bluetooth module uses USB interface, and Dual Band Wireless Module use both PCIe + USB interface
| Model Name | MTG-GM200 |
| Bus Type | M.2 M Key |
| Chipset | N/A |
| Number of Ports | 1x M.2 E Key type 2230/2242 socket |
| Transfer Rate | N/A |
| Dimensions | N/A |
| Operating Temperature | -40ºC to 80ºC |
| Storage Temperature | -20°C to 80°C |
| OS Compatibility | Windows 2000/XP/2003/Vista/7/8/10, Linux, Mac OS |
